7. Check the flowswitch.
a. Turn the system off and disconnect the connector (J49) on the AC Control PCB. Connect and ohm-
meter across the connector. The ohmmeter should read infinite ohms.
b. Turn the laser on and hold the key in the II position. The ohmmeter should read zero ohms.
8. Check the Footswitch.
a. Unplug the footswitch and verify the “ATTACH FOOTSWITCH” message is displayed and the sys-
tem goes to STANDBY.
b. Reconnect the footswitch into the system and verify the “ATTACH FOOTSWITCH” message goes
away, then place the system into READY.
c. Depress the footswitch and verify the system fires.
NOTE: On Ho/Nd:YAG systems, confirm that the “DUAL FOOTSWITCH” message is dis-
played when the footswitch is disconnected.
9. Check the LCD color display.
a. Verify the LCD color display is operating properly.
b. Verify the LCD color display inputs are functional.
c. Verify the aiming beam responds to OFF, LOW, MEDIUM and HIGH settings.
d. Fire into the power meter for several seconds, noting the power reading on the power meter. Con-
firm that the total energy display value has incremented, then confirm that the value clears back to
zero when RESET is depressed.
10. Check the Remote control Panel.
The Remote Control Panel comes as an option on the Ho & Ho/Nd:YAG versions of the VersaPulse
PowerSuite lasers. If the laser has a Remote Control Panel, perform the following procedure and con-
firm the proper operation of the Remote Control Panel
