LUMENIS VersaPulse PowerSuite - Fourth Service Screen - Plot Energy Screen

7528%/(6+227,1* 9HUVD3XOVHPowerSuite6HULHV6HUYLFH0DQXDO
 5(9%
FIG. 5.15: FOURTH SERVICE SCREEN (PLOT ENERGY SCREEN)
DGYLVRU\DQGRUIDXOWPHVVDJHVRQWRSOLQH
5(78510$,1 6$)(7<





0$,16$)(7<(1(5*<
ODVHU ODVHU ODVHU ODVHU
WLPH
GRAPH TITLE SHOWS EITHER
"MAIN" or "SAFETY" ENERGY
SIGNALS
RETURN TO
SVC.SCREEN #2
LASER
CHANNEL
LEGEND (EACH
LASER SHOWN
BY DIFFERENT
COLOR)
LASER PULSE
ENERGY
ACTUAL LASER
PULSE
ENERGIES
(SHOWN FROM
FIRING IN
SERVCE MODE)
SHOW "MAIN"
ENERGY SIGNALS
SHOW "SAFETY"
ENERGY SIGNALS

-

AFTER FIRING
IN "USER
MODE" THE
GRAPH WILL
SHOW
REQUESTED
ENERGY, 20%
HI/LO LIMITS,
AND ACTUAL
PULSE
ENERGIES
