2.1 INTRODUCTION
WARNING: Installation by untrained persons is a potential hazard to the persons doing the installations,
others present, and to the equipment itself. In addition, improper installation is a potential hazard to the
user, persons present during use, and patient.
These installation instructions are provided for use by Lumenis Service Engineers who have completed
certification service training on the VersaPulse® PowerSuite™ laser. Installation by untrained persons is a
potential hazard to the person or persons performing the installation, others present and to the equipment
itself. In addition, improper installation is a potential hazard to the user, persons present during use and
patient.
2.1.1 Site Inspection
1. Check for proper site set up. This includes proper AC service and adequate space for the console.
AC power configuration: The VersaPulse PowerSuite requires 220 VAC±10%, 50/60 Hz, 30 Amps (32
Amps for 100W Holmium) single phase electrical service. The power cord is a 26 ft. cable with two
conductors and a ground. An AC Control PCB behind the right side cover allows for tapping of the
isolation transformer to the setting closest to the incoming electrical service. The system can be hard
wired to the electrical service or installed to the electrical service with a plug and receptacle. Custom-
ers are responsible for supplying electrical connections (i.e., electrical receptacle and mating plug).
Console dimensions and weight: The console measures 36” L x 18” W x 39” H. It weighs approxi-
mately 350 lbs. A minimum of 18” of air space is required around the unit to provide adequate cool-
ing air circulation.
The system requires approximately 2.5 gallons of distilled water for its closed loop cooling system.
The coolant must be added as described in this procedure.
Complete specifications for the VersaPulse PowerSuite laser are included later in this section and in
the VersaPulse PowerSuite laser Operator Manual. Contact Technical Support in Santa Clara, CA. if
there are any questions concerning site preparation.
