Application Manual CDA3000
5-81
5 Software functions
1
2
3
4
5
6
A
DE
EN
FR
Status word 419-IOSTA
Status word 419-IOSTA for factory setting DRV_1 with
ENPO = 0 (off)
Digital output OSD02 operates the relay when the inverter is “ready to
start”. This is indicated by bit 7 in the bar graph and hex value 0080H on
the display.
Bit I/O Function DISP
BARG
9 8 7 6 5 4 3 2 1 0
0 ENPO Digital hardware enable input 0001H
1 ISD00 Digital input 0002H
2 ISD01 Digital input 0004H
3 ISD02 Digital input 0008H
4 ISD03 Digital input 0010H
5 OSD00 Digital output 0020H
6 OSD01 Digital output 0040H
7 OSD02 Digital output (relay) 0080H
8 ISA00 Analog input in digital function 0100H
9 ISA01 Analog input in digital function 0200H
Table 5.44 Status word IOSTA in subject area VAL
Input/
output
Function [input/output] DISP
BARG
9 8 7 6 5 4 3 2 1 0
ISD00/OSD02 Start clockwise/ready to start 0082H
ISD01/OSD02 Start anti-clockwise/ready to start 0084H
ISD02/OSD02 Slow jog/ready to start 0088H
ISD03/OSD02 Not assigned/ready to start 0090H
Table 5.45 Status word IOSTA in subject area VAL
