Lust CDA3000 - 65 CS-Characteristic Data Switchover (CDS)

5-112
Application Manual CDA3000
5 Software functions
5.5.6 _65 CS-Charac-
teristic data
switchover
(CDS)
Parameters for characteristic data set switchover
Functional areas with characteristic data sets
Function Effect
• Online switching is possible
between two characteristic
data sets.
• Adaptation of the motor
dynamics to the application
• Operation of two different
motors on one inverter
module
Parameter Function Value range FS Unit Online
650-CDSAC Characteristic data set (CDS) active see Table 5.67 0
651-CDSSL Control location for switchover of
characteristic data set (CDS)
see Table 5.71 OFF

652-FLIM Limit frequency for switchover to CDS -1000 ... 1000 20 Hz

Table 5.68 Parameters from subject area _65CS Characteristic data
switchover
Explanatory notes
• Any application data set may contain a second characteristic data
set.
• An overview of the functional areas containing parameters for the
second characteristic data set is presented by Table 5.69.
Subject area Parameter
Analog inputs Scaling parameter
Clock input/clock output Scaling parameter
Fixed frequencies All parameters
Frequency limitation All parameters
Reference structure Min., max. and fixed frequency
Driving profile generator Ramps
Current-controlled acceleration All parameters
Voltage Frequency Control All parameters
IxR load compensation All parameters
Slip compensation All parameters
Table 5.69 Subject areas with parameters in the second characteristic
data set (CDS)
