5-94
Application Manual CDA3000
5 Software functions
Baud rates of CAN controllers
Status word of user module 583-IOEXT
576-OP1RV
SW version of communication module at option
slot
* 0.00
577-OP2RV * 0.00
578-OPTN2 Assignment of option module * NONE
579-OPTN1 Assignment of option module * NONE
580 -COADR
CAN
open
device address
1 ... 127 1
581 -COBDR
CAN
open
controller baud rate
25 ... 1000 500
582 -CPADR Profibus DP device address 0 ... 127 0
583-IOEXT Status word of user module 0000H ... FFFFH 0000 Hex
* module-dependent
Parameter Function Value range FS Unit Online
Table 5.54 Parameters from subject area _570P Option modules
Explanatory notes
• All option modules communicate with the CDA3000 inverter module
based on the standard of the
CANLust protocol.
• The watchdog monitoring is deactivate to 0 ms at the factory.
CAN system Parameter Values [bit/s]
CAN
Lust
489-CLBDR 25, 50, 75, 125, 250, 500
CAN
open
581-COBDR 25, 125, 500, 1000
Table 5.55 Transmission speed of CAN controllers
I/O Function Hex value Bit=1
- Module detected and logged onto bus 8000H 15
IED00 Digital input 8001H 15/0
IED01 Digital input 8002H 15/1
IED02 Digital input 8004H 15/2
IED03 Digital input 8008H 15/3
Table 5.56 Status word IOEXT of user module
