5-128
Application Manual CDA3000
5 Software functions
Figure 5.46 Dependency of the ramp steepness on the device rated current
and load case dimensioned to the current limit CLCLx
Attention: In lifting applications, regenerative load from the lowering
action during braking may cause the drive to be accelerated
as a result of the apparent current I
S
.
100
25
0
50
75
10050
15/16 CLCLx
I
N
in [%]
von CLCLx
ACCRx
DECRx [%]
