Application Manual CDA3000
6-27
6 Control modes
1
2
3
4
5
6
A
DE
EN
FR
The following example illustrates the relative current conditions
when parameters are not optimized and when they are opti-
mized.
Non-optimized setup:
(1) Effective value of active current
(2) Active current after filter for IxR
(3) Control reference
(4) Voltage change by IxR
Figure 6.13 Scope recording with motorized load torque of 8 Nm on a 1.5 kW
asynchronous motor with holding brake and 100% current injec-
tion
(1)
(2)
(3)
(4)
