Lust CDA3000 - Terminal Assignment 3

Application Manual CDA3000
2-17
2 Inverter module CDA3000
1
2
3
4
5
6
A
DE
EN
FR
DE
EN
FR
Example: risk of disturbance
Figure 2.5 Disturbance of the analog input
Note: The analog inputs may only be used either both in analog or
bothindigitalmode.Itisnotpermissibletomixtheanalog
inputs with one in analog mode and one in digital mode.
CDA3000
X2:1, U
R
X2:2, ISA00
X2:4, AGND
X2:14/17, DGND
Dig. input
System field signals
