Pilot’s Guide 3-1
CHAPTER 3
OPERATION - REMOTE MOUNT
INTRODUCTION
Operational control of the Remote Mount Lynx NGT-9000R is
accomplished with a CP-2500 Control Panel or a compatible control
panel. This chapter describes the operation of the CP-2500 interfaced
to the Lynx NGT-9000R. Details on the optional cockpit switches and
indicator lamps are provided in chapter 4.
POWER ON
1. There is no power on/off switch for the Remote Mount Lynx NGT-
9000R. Depending on the aircraft, use either the battery switch or
avionics master switch to apply power. Normal operation begins
within 20 seconds of applying power. During start up the unit
checks for valid conguration data and initializes self tests.
2. If not already accomplished, press the small knob button to apply
power to the CP-2500 Control Panel.
3. The Lynx NGT-9000 GPS begins acquiring position.
a. After power is applied to the CP-2500 and the self test passes,
the CP-2500 briey displays “OK” (or a status message is
seen). Followed by the scrolling of the rmware and hardware
levels of the CP-2500 (approximately 15 seconds). The CP-
2500 then reverts to normal operation. The message “GPS-
INIT” will be shown for approximately until a GPS position is
acquired.
• If an ADS-B System Fail is displayed after approximately 2
minutes, then the GPS position was not acquired. Verify that
the aircraft (and GPS antenna) have a clear view of the sky.
If the problem continues.
b. If installed the ADS-B Out Fail lamp is Off for 2 minutes and
then ashes (1 second On/Off) indenitely until a GPS position
is acquired. Normally, GPS acquisition occurs within the rst
minute and therefore no lamp ashing occurs.
