Lynx NGT-9000 Pilot's Guide

Lynx
®
NGT-9000
Pilot’s Guide 1-1
Description
CHAPTER 1
DESCRIPTION
INTRODUCTION
The Lynx NGT-9000 family of products are a Mode S Level 2 dens
Class 1 Transponder with an integrated GPS receiver providing
Automatic Dependent Surveillance-Broadcast (ADS-B) output using
1090ES (Extended Squitter). The Lynx NGT-9000 also receive ADS-B
data via 1090ES and UAT (978 MHz Universal Access Transceiver).
The panel mounted version of the Lynx NGT-9000 has a multifunction
touch screen display that allows the user to view transponder, trafc,
and weather information. The touch screen provides the means
to select screen views and interface with transponder, trafc, and
weather displays. See Figure 1-1.
The remote version of the Lynx NGT-9000 provides the same
functionality as the panel mount, but is controlled using a compatible
alternate display or controller. See Figure 1-2.
In addition to ADS-B surveillance, some models of the Lynx
NGT-9000 include an Active Trafc Advisory System (TAS) as well
as support for antenna diversity. Table 1-1 provides model and part
number information. The TAS and Diversity options are software
activated features.
MODEL PART NUMBER TAS DIVERSITY REMOTE
NGT-9000 9029000-20000 No No No
NGT-9000+ 9029000-20000 Yes No No
NGT-9000D 9029000-20000 No Yes No
NGT-9000D+ 9029000-20000 Yes Yes No
NGT-9000R 9029000-40000 No No Yes
NGT-9000R+ 9029000-40000 Yes No Yes
NGT-9000RD 9029000-40000 No Yes Yes
NGT-9000RD+ 9029000-40000 Yes Yes Yes
Table 1-1: Model Options
The installed ADS-B OUT system has been shown to meet the
equipment requirements of 14 CFR 91.227.
