Lynx NGT-9000 Pilot's Guide

Lynx
®
NGT-9000
Pilot’s Guide2-34
Operation - Panel Mount
Figure 2-12: Traffic Display Mode and TAS Traffic Zone Graphic
0.2 nmi
0.55 nmi
+2700 ft
–2700 ft
+9000 ft
–9000 ft
–9900 ft
*15 seconds for non-altitude reporting intruder aircraft (TAS Only)
Not To Scale
+800 ft
+1200 ft
–800 ft
–1200 ft
+600 ft
–600 ft
Look Down (BLW)
Look Up (ABV)
Normal (NRM)
0 ft
**20 seconds for non-altitude reporting intruder aircraft (TAS Only)
Unrestricted (UNR)
+9900ft
Up to 35 nmi
4 nmi
– Traffic Advisory (TA) (airborne Non-directional)
– Proximity Advisory (PA) (airborne Non-directional)
–Other Traffic(OT)(airborne Non-directional)
CPA = Closest Point of Approach
– Traffic Advisory (TA) (airborne directional)
– Proximity Advisory (PA) (airborne directional)
–Other Traffic(OT)(airborne directional)
TAS Sensitivity Level A *
This area or 20 seconds to CPA
TAS Sensitivity Level B **
This area or 30 seconds to CPA
Up to 35 nmi
Up to 35 nmi
