Lynx NGT-9000 - Acknowledge Button; Selected Traffic Info Button (I); TIS-B no Coverage Indicator; Figure 2-10: Traffic Options Screen - Settings

Lynx
®
NGT-9000
Pilot’s Guide 2-23
Operation - Panel Mount
Acknowledge Button
The Acknowledge Button is located on the right side of trafc screen
and appears as a speaker icon. The acknowledge button is available
when the optional TAS or ATAS function (Release 2.0 or greater) is
congured and after a traffic advisory is detected. The Acknowledge
button is used to cancel the audio from a Trafc Aural. The TA will still
be active on the display.
Selected Traffic Info Button (i)
The selected trafc info button appears on the left side of both the left
and right screen after a trafc symbol is pressed. When the button is
tapped a trafc information window is located over the top of the trafc
screen.
TIS-B No Coverage Indicator
When congured to be enabled (required in the U.S.), the indicator
is located next to the Zoom Out button and is shown when TIS-B /
ADS-R data is not available in the area (i.e. out of range of a ADS-B
ground station).
• The indicator is also shown if a problem exists with the NGT-9000
System. See the troubleshooting section.
• The indicator will not be shown when TAS (if installed) is operational
(i.e. installed, not failed, not in standby).
Figure 2-10: Traffic Options Screen - Settings
Status Settings
Done
Initial Traffic Altitude Mode:
Normal
Above Unrestricted
BRT
VFR Code
1200
FLTID
AAA 1234
