Pilot’s Guide 2-33
Operation - Panel Mount
Table 2-3: TAS Traffic Advisory Situations
NO. OWN
SHIP ALT
OWN SHIP
GND SPEED
OTHER AIRCRAFT IS
DETECTED
1
Below
2000 ft
AGL
Within a 0.2 nmi horizontal
radius and a +/- 600 ft relative
altitude.
2 Within 15-20 sec of CPA *
3
Above
2000 ft
AGL
Within a 0.55 nmi horizontal
radius and a +/- 800 ft relative
altitude.
4 Within 20-30 sec of CPA *
5
Has in-
valid AGL
Altitude
Available and
> to 120 knots
Within a 0.55 nmi horizontal
radius and a +/- 800 ft relative
altitude.
6 Within 20-30 sec of CPA *
7 Available and
< 120 knots
Within a 0.2 nmi horizontal
radius and a +/- 600 ft relative
altitude.
8 Within 15-20 sec of CPA *
Sensitivity Level A Sensitivity Level B
* CPA means Closest Point of Approach
** Ground speed is not available whenever the GPS navigation
information is not available.
