Pilot’s Guide3-4
Operation - Remote Mount
View Pressure Altitude
1. Rotate the large knob until the “Altitude” is shown.
2. Press the small knob to view.
Set Flight ID
The ight ID function is optional and is part of the conguration options
set during installation of the NGT-9000.
1. Rotate the large knob to select ID.
2. Press the small knob to select the rst digit.
3. Rotate the small knob to change the digit (CCW) or character
(CW).
4. Rotate the large knob to move the cursor to the next digit.
5. Press the small knob to commit.
Deactivate the Flight ID
1. Rotate the large knob CW to move the cursor off the right side of
the display.
2. Continue rotating unit only dashes ll the display.
3. Press the small knob to commit.
IDENT Activation
1. Press the I (IDT) button.
2. The IDENT message is sent by the ADS-B unit for 18 sec.
3. Observe that IDENT is momentarily displayed.
The use of this button is directed by Air Trafc Control (ATC). When
instructed by ATC, the IDENT (IDT) must be selected ON.
VFR Code Select
Press the V (VFR) button to set the squawk code to a programmed
VFR code that preset in the menu (see VFR code below).
• Typically the VFR code is set to 1200 (in the United States).
• Press the button again returns the code to the previous squawk
code.
