Operation - Panel Mount
Defining Terrain Alerts
A caution alert as an alert that requires immediate pilot awareness
and corrective action usually necessary involving stop descending
or initiate either a climb or a turn, or both as necessary, based on
analysis of all available instruments and information.
A warning alert as an alert that requires immediate pilot action to initiate
and continue a climb that will provide maximum terrain clearance, or
any similar approved vertical terrain escape maneuver, until all alerts
cease. Vertical maneuvers are only recommended, unless either
operating in visual meteorological conditions (VMC), or the pilot
determines, based on all available information, that turning in addition
to the vertical escape maneuver is the safest course of action, or both.
Traffic Button
This button is located on the far left side of the screen and is labeled
“TFC” with a left facing triangle. Tap the button to return to the Trafc
Application screen.
Zoom Buttons
Zoom In (+) and Zoom Out (-) buttons are located on the bottom of
screen. The buttons are used to change the display range shown on
the display. Display range options for the Graphic Application screen
are 2 (minimum), 6, 12, and 24 (maximum) nmi.
Limitations
• The TAWS function shall not be used as a navigation instrument. It
is not intended to provide navigational guidance nor to relieve pilots
from following published navigational procedures, routes, altitude
restrictions, and/or instructions from air trafc control agencies
except in response to alerts to avoid potentially hazardous terrain
and/or obstacles. The terrain screen is intended to serve as a
situational awareness tool only.
• Terrain elevation recorded in the database refers to the actual
ground or water; it does not include trees, shrubs, or ice.
• TAWS does not operate in north of 70° N or south of 70° S.
• TAWS will use all airport runways included in the database. Contact
Jeppesen
®
if a runway is not included in the database.
