Lynx NGT-9000 Pilot's Guide

Lynx
®
NGT-9000
Pilot’s Guide 1-7
Description
EQUIPMENT DESCRIPTION
The Lynx NGT-9000 MSS family consists of the following standard and
optional equipment. Refer to the Aircraft Flight Manual Supplement to
determine what optional equipment is installed. Chapter 5 provides a
list of optional cockpit switches and lamps.
Required Equipment
• GPS Antenna
• L-Band (978MHz/1030/MHz/1090MHz) Antenna
• Detachable Conguration Module (DCM)
Optional Equipment
• Directional Antenna (required for TAS operation, and models with
TAS and diversity operation)
• Additional L-Band Antenna (required for diversity operation, and
no TAS operation)
• Trafc Display
• Weather Display
• WiFi Serial Adapter and Personal Electronic Device (PED)
• CP-2500 Control Panel (required for the remote mount version)
• WX-500 Stormscope (panel mount version only)
GPS Antenna and Internal GPS Receiver
The GPS utilizes signals from Global Positioning System (GPS)
satellite constellation and Satellite-Based Augmentation Systems
(SBAS). The Lynx NGT-9000 has an internal GPS function that pro-
vides position, velocity, time and integrity (NIC, NAC etc) information
to the applications. The antenna is located on the top of the aircraft.
L-Band Antenna
The L-Band antenna is used by the Lynx NGT-9000 to receive
1030MHz, receive and transmit 1090MHz and receive 978MHz. It is
located on the bottom of the aircraft.
A second L-Band antenna is installed on the top of the aircraft for
models with Diversity. Installations with both TAS and Diversity
options can use the TAS directional antenna instead of the second
L-Band antenna.
