Lynx
®
NGT-9000
Pilot’s Guide2-8
Operation - Panel Mount
Table 2-2: Left Screen Applications
Right Screen
The right screen has between two and six application indicators. The
number of indicators is dependent on the feature enablement.
The two screens that are always available are the Trafc and the
FIS-B Graphical Data Screen.
The Trafc Birds-eye display of trafc and ownship for the purpose
of supporting the Enhanced Visual Acquisition (EVAcq) and Basic
Airborne (AIRB) CDTI applications. This includes display of trafc
advisories, when installed and enabled (TAS or ATAS Optional).
The FIS-B Weather Graphic screen is a simplied moving map display
with depiction of ownship and the ability to selectively overlay graphical
FIS-B products such as METAR, TAF, NOTAMs, AIRMET, SIGMETs,
TFR and NEXRAD.
The following four screens are dependent on the feature enablement:
TAWS, Lightning, FIS-B Graphical Winds and Temps Aloft, and FIS-B
Textural Data.
The Terrain Awareness and Warning System screen displays a birds-
eye display of terrain, obstacles, airports, and ownship for the purpose
of supporting a Class B TAWS.
The Lightning screen displays electrical discharges from thunderstorms
within a 200 nmi radius of the aircraft. This Lightning data depicted as
cells or strikes. A “Nearby Strike Indicator (lightning bolt)” is shown
over the lightning application Dot when storm activity is detected.
The FIS-B Weather Graphic Winds & Temp Aloft screen is a simplied
moving map display with depiction of ownship and the ability to
selectively overlay winds and temps aloft at the desired ight level.
The FIS-B Weather Textual Data screen displays airport associated
textual products provided by FIS-B including METAR, TAF, NOTAMs.
The application indicators and their screens have the following order
(from left to right) when enabled: Trafc, TAWS, Lightning, FIS-B
Graphic Data, FIS-B Graphical Winds & Temps Aloft, and FIS-B
Textual Data.
