MacDon A40D - Lubrication Points: Knife and Gearbox

262335 94 Revision A
4.6 Lubrication Points: Knife and Gearbox
There are several points on the knife and the gear which will require lubrication.
1022228
A
B
C
C
Figure 4.6: Knife and Gearbox
A - Oil the Knife Daily Except in Sandy Soil (SAE 30) C - Knife Drive Box (2 Places)
4
B - Check the Roll Gearbox (1 Place)
5
LUBRICATING THE MACHINE
4. Check oil level with the header down on level ground.
5. Header should be on the ground.
