3.4 Tilting the Header into Field Position
DANGER
Ensure that all bystanders have cleared the area.
DANGER
Ensure spreader bar or chain is secured to the forks so that it cannot slide off the forks or towards the mast as the
header is tilted to the ground.
To tilt the header into the field position, follow these steps:
1. Attach either a spreader bar or chain to forks.
2. Drive the lifting vehicle to approach header from its underside.
Table 3.1 Chain Specifications
Chain Type
Overhead lifting quality (1/2 in.)
Minimum Working Load
2270 kg (5000 lb.)
ASSEMBLING THE MACHINE
