MacDon A40D - Leveling Header - M1 Series Windrower

262335 110 Revision A
5.8 Leveling Header – M1 Series Windrower
The windrower lift linkages are factory-set to provide the proper header level, and should not normally require adjustment.
DANGER
To prevent bodily injury or death from the unexpected startup of the machine, always stop the engine and remove the
key from the ignition before leaving the operator’s seat for any reason.
DANGER
Ensure that all bystanders have cleared the area.
1. Start the engine.
1015851
A
B
Figure 5.30: HPT Display
2. Press rotary scroll knob (A) on Harvest Performance
Tracker (HPT) to display the QuickMenu page.
3. Rotate scroll knob (A) to highlight HEADER FLOAT
symbol (B) and press scroll knob to select. The SET-UP
FLOAT page displays.
1019607
A
Figure 5.31: HPT Display
4. Press soft key 3 (A) to remove float.
PERFORMING PREDELIVERY CHECKS
