214325 32 Revision A
Figure 3.36: AGCO Group Feeder House
5. Use lock handle (B) to engage lugs (A) with adapter.
CAUTION
Never start or move the machine until you are sure all bystanders have cleared the area.
6. Start engine and lower header.
7. Stop engine and remove key from ignition.
NOTE:
The CA25 Combine Adapter is equipped with a multicoupler that connects to the combine. If combine is
equipped with individual connectors, a multicoupler kit (single-point connector) must be installed. Refer to Table
3.3, page 32 for a list of kits and installation instructions that are available through your combine Dealer.
Table 3.3 Multicoupler Kits
Combine
Kit Number
Challenger
71530662
Gleaner R/S Series
71414706
Massey Ferguson 71411594
Figure 3.37: Adapter Multicoupler
8. Raise handle (A) to release multicoupler (B) from
adapter.
ASSEMBLING HEADER AND ADAPTER
