214325 71 Revision A
Figure 3.130: Combine Coupler
10. Unscrew knob (A) on combine coupler (B) to release
coupler from combine receptacle and clean coupler.
Figure 3.131: Receptacle Cover
11. Remove CA25 receptacle cover (A).
Figure 3.132: Receptacle Cover
12. Place CA25 receptacle cover (A) onto
combine receptacle.
ASSEMBLING HEADER AND ADAPTER
