Figure 3.84: Challenger/Massey Controls
CLAAS combines:
CLAAS (with factory-installed fore-aft / header tilt switch): Newer CLAAS combines use a combination of the
reel fore-aft switches on the control handle and a factory-installed auxiliary rocker switch which toggles between
reel fore-aft and header tilt functionality.
Figure 3.85: CLAAS 700 Console
1. Press HOTKEY switch (A) on operator’s console to
deck plate position (the header icon [B] with the arrows
pointing to each other).
