Section 5 – PERIODIC MAINTENANCE
Mini-Crawler Crane M A E D A
5-26 9/2020 MC285CB-3
Maintenance Every 50 Hours
Grease Machine Units
Caution: Grease type varies with greasing
points. Failure to grease properly may cause
the machine to shorten its useful life.
Caution: Greasing a new machine is required
once every 10 hours until the machine attains
the first 100 hours of operation that initial fit
emerges.
• Use proper grease specified below according to
the greasing points.
No.
Greasing point Grease type
1
boom mounting
1 place
Lithium
grease
2
derrick cylinder
bottom
1 place
3
derrick cylinder
rod side
1 place
4
outrigger rotary
4 places
5
outrigger
cylinder bottom
4 places
6
outrigger
cylinder rod
4 places
7
Greasing of the
slewing gear
2 places
8
Greasing of the
boom slide plate
8 places
grease
9
sides and
underside of the
Each
boom
10
boom extending
and retracting
4 places
Rope oil
11
Greasing of the
winch wire rope
1 piece
12
outrigger top
4 places
Lithium
grease
1. With the use of the grease gun, inject grease
through corresponding grease plugs
indicated in the arrow (see the following
page) of the above table “No.1 to 8, 12”.
2. Wipe off old grease squeezed out after
greasing.
3. Place the outriggers when greasing the
outrigger cylinders.
4. Place the boom derricking lever in the “Raise”
position (pull it toward you) to raise the boom
slightly for greasing the derricking cylinder
mounting pin and slide plate that is located on
top of the boom.
5. Place the boom telescoping lever in the
“Extend” position (push it toward the front) to
extend the boom for greasing both sides and
underside of the boom and wire rope.
6. Apply red rope grease to prevent wire rope
abrasion and rust formation.
With the rope surface cleaned, grease the
rope with a brush.
To Next Page
