Maeda MC285CB-3 - Radio Remote Control System Specifications

Section 3 – PRINCIPLE SPECIFICATIONS LIST Mini-Crawler Crane M A E D A
3-6 9/2020 MC285CB-3
Radio Remote Control System Specifications
System / Item Radio remote control
Radio frequency 2402-2480 MHz band
Transmission output 100 mW
Channel spacing 1 MHz
Reachable range of radio waves 100 m or longer (under a good condition where there is no radio interference)
Unique address Extracted and set from 1 million or more addresses at the time of shipment from factory
Waterproof IP65
Transmitter antenna Built-in type
Operating
status display
Status LED
Battery status display
No reception display
Monitor LED
Receiver power status display
Transmitter power status display
Feedback
Telegram display
Safety device
Emergency stop switch (EMO)
Misoperation avoidance function during interruption of radio remote control
Automatic power OFF device (Auto power off device)
Transmitter stop function when battery capacity decreases
Alarm switch
Transmitter voltage Battery BA405000 (6 VDC at 1500 mAh)
Receiver voltage Power of crane main body (12 VDC)
Continuous operating hours of
Transmitter
Approximately 20 hours (Changes depending on usage environment)
Ambient operating temperature -20°C to +70°C
Transmitter mass Approx. 1.8 kg (including battery)
Operation items of Transmitter
Operation lever
Outrigger 4 GROUND/STOWAGE / Boom LOWER
Outrigger 3 GROUND/STOWAGE / Hook RAISE/LOWER
Outrigger 2 GROUND/STOWAGE / Boom EXTEND/RETRACT
Outrigger 1 GROUND/STOWAGE / Slew
Operation switch
Transmitter power switch
Micro speed switch
Boom raising cancel switch
Horn switch
Emergency stop (EMO)/Transmitter power OFF switch
Rotary switch Operation mode selector switch
Dial switch Display operation switch
