Rated Total Load Chart for
Standard Specification
1. All rated total loads are indicated in
kilograms.
2. This load radius shown in this chart is based
on practical working including boom
deflection due to loading. The crane user
must calculate and compensate for boom
deflection as the load is lifted.
3. Deductions from rated total loads must be
made for the weight of hook block, ball/hook,
slings, rigging or other suspended gear.
4. The slewing range will be restricted if the
outrigger angle is not at the standard
extension.
5. The Rated Total Load Chart capacities are
based on using the factory supplied Standard
Wire Rope. If you replace the wire rope, use
the correct specification, that meets or
exceeds the standard wire rope strength and
specification.
6. Standard wire rope specification: 6xFi (29)
IWRC, 10 mm diameter, 48 m
Specified breaking load: 41.2 kN
Rated Total Load Chart–4 Falls
Rated Total load Chart - 4 falls
The unit of loads: kg
2.535 m Boom 2.536 – 4.075 m Boom 4.076 – 5.575 m Boom 5.576 – 7.075 m Boom 7.076 – 8.575 m Boom
Load
radius
(m)
Loaded
Boom
angle
(deg)
Outrigger
position
Loaded
Boom
angle
(deg)
Outrigger
position
Loaded
Boom
angle
(deg)
Outrigger
position
Loaded
Boom
angle
(deg)
Outrigger
position
Loaded
Boom
angle
(deg)
Outrigger
position
Load
radius
(m)
MAX
Other
than
MAX
MAX
Other
than
MAX
MAX
Other
than
MAX
MAX
Other
than
MAX
MAX
Other
than
MAX
1.4
48.0 2820 1720 65.5 2820 1720
1.4
1.5
45.0 2520 1070 64.0 2520 1070
1.5
2.0
23.0
1920
630
56.0
1920
630
2.0
2.5
46.5 1570 520
2.5
3.0
35.5 1220 390 53.5 1220 510
3.0
3.5
19.0 970 350 47.0 970 410
3.5
3.6
46.0
930
370
57.0
820
400
3.6
4.0
39.0 780 330 52.5 740 330 60.0 550 330
4.0
4.5
29.5 630 280 47.5 580 280 56.0 400 280
4.5
5.0
15.5
530
200
41.5
480
230
52.0
340
230
5.0
5.5
34.5 430 180 47.5 300 180
5.5
6.0
26.5 380 160 43.0 270 160
6.0
6.5
14.0 350 130 37.5 230 130
6.5
7.0
31.5 200 100
7.0
7.5
24.0 180 80
7.5
8.0
13.0
150
70
8.0
Hook block mass weight 30 kg standard supplied Maeda hook block or ball.
