Section 4 – TRAVEL CONTROLS Mini-Crawler Crane M A E D A
4-6 9/2020 MC285CB-3
TRAVEL CONTROLS
Control Location
Fig. 4-5
1 - Motor Speed Adjuster Dial
2 - L. H. Travel Lever/Locking lever
3 - R. H. Travel Lever/Locking lever
4 - Starter Switch
5 - Emergency Stop Switch (EMO)
6 - Horn Switch
7 - Working Light Switch
