Manitowoc Published 05-09-17, Control # 011-29_v2 4-61
16000 OPERATOR MANUAL SET-UP AND INSTALLATION
4
FIGURE 4-32 continued
4
Single Part
Reeving
11
9
10
5
8
6
Multiple Part Reeving Dead
Ended at Upper Boom Point
7
2b
3b
4
5
A11993
Item Description Item Description
1 Wire Rope Guide 5b Pin
2a Lower Boom Point 6 Weight
2b Extended Upper Boom Point (lower sheaves) 7 Lift Plate
3a Standard Upper Boom Point 8 Load Block
3b Extended Upper Boom Point (upper sheave) 9 Weight
4 Block-Up Limit Switch 10 Lift Block
5 Chain 11 Weight Ball
5a Shackle
