marposs P3UP - 7.3.2.4 TIP t1 and TIP t2 Parameters; 7.3.2.5 FBK STEP Configuration

Installation and User Manual
77
7.3.2.4 TIP t1 and TIP t2 (optional)
These two parameters manage the trigger of the C1 control. The C1 control is temporarily disabled for the t2
time and subsequently re-enabled for the t1 time, continuously until the trigger of C0.
When C1 is disabled on the display the TIP message appears
TIP t1 programmable from 0.1 to 30 seconds. (30 s
default)
TIP t2 can be set between 0.1 seconds (default) and
5 seconds, in steps of 100 seconds.
7.3.2.5 FBK STEP
This parameter defines the pulse feedback correction increment or decrement value (STEP)
1. Press
to display any modifications to
the FBK STEP parameter;
2. Rotate the knob to set-up the correction:
 Step = 0.00001” / 0.2µm
 Step = 0.00002” / 0.5µm
 Step = 0.00004” / 1µm
 Step = 0.00008” / 2µm
3. Press
to confirm and return to the
programming menu; or
to return to
the programming menu without confirming.
