292 CONTENTS
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
AnyEdge"
"ExposureMode = Timed"
OnAnyEdge Start the exposure of a frame when
the trigger input level changes from
high to low or from low to high.
21.3.4 Device Feature And Property List
21.3.4.1 Gray scale version
21.3.4.2 Color version
21.4 mvBlueFOX3-2024a (2.4 Mpix [1936 x 1216])
21.4.1 Introduction
The sensor uses a global shutter, i.e. light exposure takes place on all pixels in parallel, although subsequent
readout is sequential.
Feature Description
Manufacturer Sensor
Sensor name IMX249
Max. frames per second 41
Device Structure CMOS image sensor
SNR
max
[dB]
1/
45.1
DNR (normal / HDR) [dB]
1/
73 / -
Image size 1/1.2
Number of effective pixels 1936 (H) x 1216 (V)
Unit cell size 5.86µm (H) x 5.86µm (V)
ADC resolution / output 12 bit
8/10/(12)
1
Measured accord. to EMVA1288 with gray scale version of the camera
