296 CONTENTS
21.5 mvBlueFOX3-2032 (3.2 Mpix [2064 x 1544])
21.5.1 Introduction
The sensor uses a global shutter, i.e. light exposure takes place on all pixels in parallel, although subsequent
readout is sequential.
Feature Description
Manufacturer Sensor
Sensor name IMX252
Max. frames per second 119
Device Structure CMOS image sensor
SNR
max
[dB]
1/
40.3
DNR (normal / HDR) [dB]
1/
71.1 / -
Image size 1/1.8
Number of effective pixels 2064 (H) x 1544 (V)
Unit cell size 3.45µm (H) x 3.45µm (V)
ADC resolution / output 12 bit
8/10/(12)
1
Measured accord. to EMVA1288 with gray scale version of the camera
21.5.2 Spectral Sensitivity
Figure 1: Spectral sensitivity mvBlueFOX3-2032G
MATRIX VISION GmbH
