9.1 Dimensions 53
9 Technical data
9.1 Dimensions
9.1.1 Standard model
Figure 1: mvBlueFOX3 -xx1x dimensions and connectors
mvBlueFOX3
Size of body (w x h x l) 39 x 39 x 24 mm
Lens protrusion C-Mount CS-Mount
X 12.5 mm 7.5 mm
9.1.1.1 Mounting holes
On the bottomside, the mvBlueFOX3 provides integrated tripod mounting holes.
Figure 2: mvBlueFOX3 mounting holes
