9.4 Components 63
9.3.2 Standard model -2xxx
States Description
1. Off No power or no bootloader found.
2. White Bootloader was recognized and FPGA is booting-up.
3. Yellow mvBlueFOX3 is running.
4. Green mvBlueFOX3 is streaming images.
5. Yellow blink mvBlueFOX3 is busy (e.g. file upload).
6. White blink Waiting for USB connection (external power is connected)
7. Red Error or if you put the device into standby
9.4 Components
Features mvBlueFOX3 mvBlueFOX3-M2
Interface USB 3.0 / USB 2.0 (up to 5 Gbit/s/ up to 480 Mbit/s )
Image Memory 256 MBytes
Digital Inputs 2 as an option
Type opto-isolated with current
limiters
Digital Outputs 4 as an option
Type opto-isolated
Lens Mount (Focal Dis-
tance)
C-mount (17.526 mm in
air), CS-mount (12.526
mm in air)
C-mount (17.526 mm in
air)
Environment Ambient Temperature
Outputs Operation 0..45 deg C / 30 to 80% RH 0..40 deg C / 30 to 80% RH
without additional cooling
Storage -20..60 deg C / 20 to 90% RH
Weight without lens approx. 58.5 g approx. 53 g
Power supply
Consumption via bus < 4.5W
MATRIX VISION GmbH
