62 CONTENTS
Figure 17: DigOut mvBlueFOX3
9.2.3.2 Switching characteristics
Characteristics Symbol Test conditions Typ. Unit
Turn-On time t
ON
R
L
= 100 Ohm, V
CC
10V, I
C
= 2mA
3
us
Storage time t
S
3
Turn-Off time t
OFF
3
Turn-On time t
ON
R
L
= 1.9 kOhm, V
CC
5V, I
C
= 16mA
2
us
Storage time t
S
25
Turn-Off time t
OFF
40
Figure 18: Switching time
9.3 Status / Power LED
9.3.1 Standard model
States Description
1. Off No power or no bootloader found.
2. Red Bootloader was recognized and FPGA is booting-up or device is in standby mode.
3. Green mvBlueFOX3 is running.
4. Green blink mvBlueFOX3 is busy (e.g. file upload).
