21.10 mvBlueFOX3-2089 (8.9 Mpix [4112 x 2176]) 315
21.10 mvBlueFOX3-2089 (8.9 Mpix [4112 x 2176])
21.10.1 Introduction
The sensor uses a global shutter, i.e. light exposure takes place on all pixels in parallel, although subsequent
readout is sequential.
Feature Description
Manufacturer Sensor
Sensor name IMX255
Max. frames per second 47.5
Device Structure CMOS image sensor
SNR
max
[dB]
1/
40.2
DNR (normal / HDR) [dB]
1/
71.2 / -
Image size 1
Number of effective pixels 4112 (H) x 2176 (V)
Unit cell size 3.45µm (H) x 3.45µm (V)
ADC resolution / output 12 bit  8/10/(12)
1
Measured accord. to EMVA1288 with gray scale version of the camera
Note
Max. AOI width of color version is 4096 pixels.
21.10.2 Spectral Sensitivity
Figure 1: Spectral sensitivity mvBlueFOX3-2089G
