22.8 mvBlueFOX3-1140 (14 Mpix [4384 x 3288]) 353
Feature Description
Manufacturer Aptina
Sensor name MT9F002
Max. frames per second 6
Device Structure CMOS image sensor
SNR
max
[dB]
1/
35.1
DNR (normal / HDR) [dB]
1/
57.3 / -
Image size 1/2.3
Number of effective pixels 4608 (H) x 3288 (V)
Unit cell size 1.4µm (H) x 1.4µm (V)
ADC resolution / output 12 bit  8/10/(12)
1
Measured accord. to EMVA1288 with gray scale version of the camera
22.8.2 Spectral Sensitivity
Figure 3: Spectral sensitivity mvBlueFOX3-1140C
22.8.3 Timings
Name Value
PixelClock 96.88
VerticalBlank 15
22.8.3.1 Free running mode
To calculate the maximum frames per second (FPS
max
) in free running mode you will need following formula:
