22.8 mvBlueFOX3-1140 (14 Mpix [4384 x 3288]) 351
22.7.4 Device Feature And Property List
22.7.4.1 Gray scale version
22.7.4.2 Color version
22.8 mvBlueFOX3-1140 (14 Mpix [4384 x 3288])
22.8.1 Introduction
The sensor features several acquisition modes ("mv Shutter Mode"):
• rolling shutter ("mvRollingShutter") and
• global reset release shutter ("mvGlobalReset").
With the rolling shutter the lines are exposed for the same duration, but at a slightly different point in time:
Figure 1: Rolling shutter
In rolling shutter mode, a doubling of the exposure time clearly leads to a doubling of the gray value:
ExposureTime2
GrayValueFactor = -------------
ExposureTime1
