Note
Moving objects together with a rolling shutter can cause a shear in moving objects.
Feature Description
Manufacturer Aptina
Sensor name MT9M034
Max. frames per second 45
Device Structure CMOS image sensor
SNR
max
[dB]
1/
37.7
DNR (normal / HDR) [dB]
1/
63.4 / ≥ 115 (p. 248)
Image size 1/3
Number of effective pixels 1280 (H) x 960 (V)
Unit cell size 3.75um (H) x 3.75um (V)
ADC resolution / output 12 bit
8/10/(12)
1
Measured accord. to EMVA1288 with gray scale version of the camera
22.2.2 Spectral Sensitivity
Figure 2: Spectral sensitivity mvBlueFOX3-1012dG
