Feature Description
Manufacturer Aptina
Sensor name AR0331
Max. frames per second 21
Device Structure CMOS image sensor
SNR
max
[dB]
1/
-
DNR (normal / HDR) [dB]
1/
- / -
Image size 1/3
Number of effective pixels 2064 x 1578 (V)
Unit cell size 2.2µm (H) x 2.2µm (V)
ADC resolution / output 12 bit
8/10/12
1
Not quantifiable according to EMVA1288
22.6.2 Spectral Sensitivity
Figure 2: Spectral sensitivity mvBlueFOX3-1031C
22.6.3 Timings
Name Value
PixelClock 74.25
VerticalBlank 15
22.6.3.1 Free running mode
To calculate the maximum frames per second (FPS
max
) in free running mode you will need following formula:
