21.13 mvBlueFOX3-2124a (12.4 Mpix [4112 x 3008]) 327

Note

Max. AOI width of color version is 4096 pixels.

21.13.2 Spectral Sensitivity

Figure 1: Spectral sensitivity mvBlueFOX3-2124aG

Figure 2: Spectral sensitivity mvBlueFOX3-2124aC

21.13.3 Timings
