9.2 Camera interfaces 61
Standard
Notes
High level +3 to +24V (max. 30V)
Low level 0V (min. -30V) to +0.7V
Threshold
(Low –> High /
High –> Low)
2V +- 1V
I
max
5mA
Figure 16: DigIn mvBlueFOX3
9.2.2.2 Switching characteristics
Characteristics Symbol Test conditions Typ. Unit
Minimum trigger pulse width 5
us
Turn-On time t
ON
R
L
= 2 kOhm, V
CC
3V, I
C
=
2mA
3
Storage time t
S
12
Turn-Off time t
OFF
20
Rise time t
r
2
Fall time t
f
7
9.2.3 Characteristics of the digital outputs
9.2.3.1 Electrical characteristics
Comment Min. Typ. Max. Unit
I
C
load current 15 mA
V
CE(sat)
@ I
C
= 7 mA 0.←-
4
V
V
OUT
Output Voltage 30 V
