336 CONTENTS
22.2.3.2 Snapshot mode
To calculate the maximum frames per second (FPS
max
) in snapshot mode you will need following formula:
(ImageHeight
*
( 1650 )) + ((VerticalBlank+2)
*
1650 )
FrameTime = ------------ ------------
PixelClock PixelClock
FPS_max = 1
-----------------------------------
FrameTime + ExposureTime
Note
The exposure time step width is limited to the sensor's row time of 41.3 us and therefore
- auto exposure with very low exposure times will perform with relatively large increments and
- exposure mode = TriggerWidth (if available) will perform with a jitter corresponding to the row time
22.2.4 Device Feature And Property List
22.2.4.1 Gray scale version
22.2.4.2 Color version
22.3 mvBlueFOX3-1013 (1.3 Mpix [1280 x 1024])
22.3.1 Introduction
The sensor uses a pipelined global snapshot shutter, i.e. light exposure takes place on all pixels in parallel, although
subsequent readout is sequential.
Feature Description
Manufacturer E2V
Sensor name EV76C560
Max. frames per second 60.9
Device Structure CMOS image sensor
SNR
max
[dB]
1/
39.9
DNR (normal / HDR) [dB]
1/
51.5 / > 100 dB (p. 250)
Image size 1/1.8
Number of effective pixels 1280 (H) x 1024 (V)
Unit cell size 5.3µm (H) x 5.3µm (V)
ADC resolution / output 10 bit
8/10/(12)
