VX30/VX50 Gen3/ECO50 Vacuum Systems Specifications 70-5
*Calculate full weights using 8 lb/gal (
1 kg/L) for water and 10 lb/gal (1.2 kg/L) for spoil.
General/Tow ECO50-500 ECO50-800
Empty Weight* 5450 lb/2472 kg 6085 lb/2760 kg
Empty Weight* w/ Boom 6650 lb (3016 kg) 7285 lb (3304 kg)
Length 175" (445 cm) 203" (516 cm)
Width 97" (246 cm) 97" (246 cm)
Height 66" (168 cm) 68" (173 cm)
Suggested Truck Spec. 26,000 GVW/14 ft (4.3 m) bed 33,000 GVW/16 ft (4.9 m) bed
