20-16 Controls VX30/VX50 Gen3/ECO50 Vacuum Excavators
SPOIL TANK SAFETY BRACE
Install red safety brace (1) over spoil tank lift
cylinder (3) rod before working near or under the
raised tank. Secure brace with safety snap pins (2).
The brace does not need to be installed when
dumping the spoil
tank. Store beneath tank lid bar
as shown when not in use.
SPOIL TANK LID SAFETY LOCK PIN
Install safety lock pins (1) as shown whenever work is
performed near or under the raised hydraulic spoil tank
door. Secure each safety lock pin with cabled hairpin (2).
Place pin in storage location (3) wh
en not in use.
