VX30/VX50 Gen3/ECO50 Vacuum Systems Maintenance - 250 Service Hours 60-37
MAINTENANCE - 250 SERVICE HOURS
Engine Maintenance
• Engine Air Cleaner - Clean/Service - V2403
• Engine Fan Belt Tension - Adjust - V2403
An Engine Operation Manual is supplied with each engine.
Refer to the manual for engine service requirements.
Refer to “Engine Maintenance,” page
75-1, for air cleaner component locations.
Breakaway Brake Circuit - Test
The trailer provided with your equipment has an electric breakaway brake which
engages if the trailer separates from the towing vehicle. The electric system requires a
12-volt 5-amp/hr battery. Perform the following system test:
Step 1: Disconnect trailer
electrical connector. Pull pin (1) out of switch (2).
Step 2: A
ttempt to move trailer forward with the towing vehicle. Substantial brake
drag should be noticed. If no brake drag is noticed, check the battery
condition and brake circuit wiring.
Step 3: When
testing is complete, insert pin back into switch. Connect trailer
electrical connector.
NOTICE: Prolonged or frequent activation of switch will discha
rge machine battery.
WARNING: Do not use breakaway device as a park brake.
