VX30/VX50 Gen3/ECO50 Vacuum Excavators Controls 20-3
INDICATORS
VX30 Indicators
(1)
High Engine Coolant Temperature
Red light comes ON when coolant temp.
exceeds prescribed level.
Remove engine load, idle engine at least 5 minutes, then turn engine
OFF. Refer to Engine Operation Manual.
(2) Low Engine Oil Pressure
Red light comes ON when engine oil pressure drops
below prescribed
level. If this occurs during operation and light does not go OFF after
engine speed > 100 rpm, turn off engine and check oil level.
(3) Battery Low
Red light comes ON when battery charge is lo
w or there is no alternator
output when engine is running. (It is normal for light to be ON if key is
ON but engine is not running.) Refer to Engine Operation Manual.
(4) Spoil Tank Full
Red light comes ON when spoil tank is full of wet m
aterial. Engine shuts
down if Spoil Tank Full Override is not ON. When vacuuming dry
materials, the Tank Full shutdown sensor does not function.
(5) Water Tank Low
Amber light comes ON when water level is low in water tank.
(6) Spoil Tank Full Override
Red light comes ON when Spoil Tank Full Override is ON.
