VX30/VX50 Gen3/ECO50 Vacuum Excavators Electronic Controller 21-5
Indicators
(1) Spoil Tank Full
When lit, indicates the spoil tank is full of wet material. Engine shuts
down if Spoil Tank Full Override is not on. When vacuuming dry
materials, the Tank Full shutdown sensor does not function.
(2) Spoil Tank Full Override
When lit, indicates the Spoil Tank Full Override is on.
(3) Water Off
When lit, indicates that water tanks are empty.
(4) Wait to Start
When lit, indicates that engine glow plugs are heating. Wait to start
engine until light goes off, and green “OK to Start” light appears.
(5) Battery Voltage Low
When lit, indicates that battery voltage is low.
(6) Engine Water Temperature High
When lit, indicates engine water temperature is high.
(7) Engine Oil Pressure Low
When lit, indicates engine oil pressure is low.
