McLaughlin VX30 Series - Manual Rotation Boom

VX30/VX50 Gen3/ECO50 Vacuum Excavators Controls 20-19
Manual Rotation Boom
(1) Power ON/OFF
(2) Boom Raise
(3) Boom Lower
(4) Boom Extend
(5) Boom Retract
(6) Brake ON/OFF
(7) Gate Valve Open/Close
(8) Battery Power Level Indicator
Green light indicates sufficient battery power.
(9) Signal Indicator
Green flashing light indicates connectiv
ity. Red light indicates no
connection.
2
1
3
5
7
4
6
8
9
