VX30/VX50 Gen3/ECO50 Vacuum Excavators Transporting the Machine 30-7
Strong Arm (Option) - Store for Transport
NOTICE: Strong Arm is not available on skid units.
Strong Arm (1)
must be locked in transport position before transporting machine.
Move Strong Arm to stowed position. Engage retainer (2) and pin (3).
WARNING: Swinging arm. Serious injury will result. Arm can swing when tank is
raised.
Always lock Strong Arm in position when not in use.
